Pop Up Socket 3 Gang + 2 USB A+C, Bright Chrome

100mm Diameter Pop Up Power Unit with 3x UK Power Sockets & no Data Ports.  Just peel back the protective film and drop it in a predrilled hole ready to go.  Supplied with a standard 2 metre lead and fitted plug for any UK Standard 3 pin socket - just like an extension socket!

The Bright Chrome Top Disc compliments the Two-Tone Black & Chrome surround and you just depress the Black button to 'pop-up' the unit about 25-30mm - and then draw it into position.  Adds that real wow factor to any kitchen, especially when used in conjunction with the flush fit adaptor ring, now supplied as standard!

This unit is predominantly manufactured from a quality Zamak (Metal) material and will enhance any kitchen, workspace or prestigious development, where power or data distribution is required.   As with all our concealed sockets, we always recommend you get a tradesperson to install this unit.

Unit comes with flush fit adaptor ring in the box.

Useful Technical Data / All Pop Up Sockets now rated to to IP54

Approx. Column Height when fully extended, from top or worktop - 240mm

Overall Outside Diameter of Top Plate with Depress Button - 120mm

Suggested Hole Size Required - See below but use a test template if in doubt
with flush fit adaptor ring (supplied) : 124mm
without flush fit adaptor ring : 100mm -0/+1mm

Thickness of Top when used without a 'Flush Fit' Adaptor - 7mm

Overall Diameter of Shoulder Washer that clamps under the worktop - 152mm
(this can be reduced down to as much as 110mm, if trimmed)

Approx. Depth required when retracted fully - 310mm
(the depth required is measured from the TOP of the worktop & includes space for the wires/cables to exit the bottom of the unit, so worktop thickness can be taken off this figure.)
