20mm Stainless Steel Rigid Foot M6 x 47mm

Our 20mm stainless steel rigid foot features a reinforced nylon base and an M6 threaded stud with a usable thread length of 47mm. With a load rating of up to 362kg using the standard reinforced nylon base, this heavy-duty machine foot provides reliable support for machinery, equipment and other demanding installations.

Each foot comes supplied with a locking nut and washer pre-assembled, helping to simplify installation and secure the foot in position. The standard black reinforced nylon base offers excellent load-bearing performance, while alternative base materials and colours are available to order to suit different applications. For installations requiring additional grip, we can also supply technical rubber bases with non-slip properties. Transparent technical bases are another option, offering a load rating of up to 415kg. We also offer self-adhesive anti-slip pads to suit each base diameter, providing an additional way to improve stability and help prevent unwanted movement.

The listed dimensions refer to the base diameter and usable thread form. If you require a different size, material or finish, contact our team to discuss special production options, subject to minimum order quantities. We offer a range of colours and finishes, which may change over time, so get in touch if you cannot find the option you need in the product dropdown.

Technical specifications

• Base diameter: 20mm
• Thread size: M6
• Usable thread length: 47mm
• Thread material: Stainless steel
• Alternative thread finish: Zinc plated (where available)
• Base material: Reinforced nylon (standard)
• Base colour: Black (standard)
• Standard load rating: 362kg
• Alternative base materials: Transparent technical material and technical rubber (available to order)
• Supplied with: Pre-assembled locking nut and washer
• Optional accessory: Self-adhesive anti-slip pad
• Special sizes and colours: Available to order, subject to minimum quantities

Load ratings

• Reinforced nylon base (standard): 362kg
• Transparent technical base (to order): 415kg
• Technical rubber base (to order): 25kg

Load ratings vary according to the base material selected.
