Screw on Cable Clamp, Small

A general purpose clip or clamp, typically used for securing wires and cables.  Originally designed as terminal covers on electric washroom products but obviously can be applied to a multitude of applications.

Similar to what you would find secures a cable in place in a 3-pin electrical plug, although this particular design is for smaller cables - with 2 screw holes for fixation.

Approximate Dimensions :

Total Length - 17.0mm
Gap for Cables - 1.2mm high, fully screwed down but will accomodate larger cables (with appropriate length screws)
Cable Gap Width - 7.2mm
Screw Hole Dia - 1.8mm
Gap between Screw holes - 12.5mm

These are available as samples though, so why not click the Orange 'Request Sample' button, or alternatitvely check out the drawing that can be found within the Technical Data tab.

We show standard colours & finishes where possible but these are constantly changing so if you require a colour not listed in the drop-down, speak to us as we may well have added it since.

  There are currently no reviews for this product. Why not submit a review?

There are currently no FAQs for this product. Do you have a question? Submit FAQ

• Dimensional Info
